Scan Speak 22W/4451T 22cm Woofer

ScanSpeak Revelator 22W/4851T00 8" Woofer, Paper Cone, 4 ohm

The Scan-speak 22W/4851T is a new addition to the Revelator line. This robust 8" woofer was designed to provide deep and accurate bass in a small enclosure. This woofer features a 2" voice coil on a titanium former, a low loss linear suspension and symmetric drive motor. The deep set hard paper cone is attached to the frame with a minimal reflection rubber surround. The 9mm X-max ensures good linear travel.

Cabinet recommendations:

1.2 cubic foot enclosure with a 3"Ø vent by 8" long for and F3 of 38Hz.
1.2 cubic foot enclosure with a 3"Ø vent by 9" long for and F3 of 32Hz.

Also written as: 22W/4851T-00, 22W4851T00, 22W 4851T 00, 22W 4851T00, 22W4851T 00, 22W/4851T, 22W /4851T-00, 22W4851T
