Scan Speak Classic 17cm Poly Cone Woofer 8 Ohms

Scan Speak Classic 17cm Poly Cone Woofer 8 Ohms
    close
    Code: P17WJ00-08
    Price: $99.95
    Shipping Weight: 6.00 pounds
    Quantity in Basket: None
    Quantity:

    Product Description:

    P17WJ-00-08

    Nominal impedance [ohm]
    8
    SPECIAL FEATURES:
    Voice coil resistance [ohm]
    5.8
    Nominal power [W]
    40
     Magnesium basket
    Short term max power [W]
    350

    Long term max power [W]
    150
     Mineral filled polycone
    Operating power [W]
    6.3

    Sensitivity [dB]
    88
     High damping rubber
    Frequency range [Hz]
    37-5000
     surround
    Free air resonance [Hz]
    37

    Voice coil diameter [mm]
    32
     Very smooth frequency
    Voice coil height [mm]
    14
     response
    Air gap height [mm]
    6

    Voice coil inductance [mH]
    0.55
     Ideal for bass reflex
    Eff. diaphragm Area [cm²]
    136

    Moving mass [g]
    14

    Magnet weight [g]/[oz]
    415/14.6

    Force factor [Bl]
    6.5

    VAS [l]
    34.7

    Qms
    1.55

    Qes
    0.45

    Qts
    0.35

    OD:

    170 mm



    CD:

    146 mm

    FT:

    4.2 mm



    ID:

    71.3 mm

    MD:

    98.1 mm



    HD:

    4xø5@ø162
