SB Acoustics SB29NRX-00 10" Passive Radiator

SB Acoustics SB29NRX-00 10" Passive Radiator
    close
    Code: SB29NRX-00
    Price: $129.99
    Shipping Weight: 3.00 pounds
    Quantity in Basket: None
    Quantity:

    Product Description:

    SB Acoustics SB29NRX-00 10" "Norex" Natural Paper Cone Passive Radiator- 290mm- 455g

    SB Acoustics SB29NRX-00 10" Coated Paper Cone Passive Radiator. Good match to the SB29SWNRX-S75 woofer. This driver is built similar to the active woofer and is a good match to the SB29SWNRX-S75 10" subwoofer.  In 0.75 to 1.0 cubic foot with that woofer you have an F3 of about 35Hz. It also mates well with the SB29NRX75-6 10" woofer. In 1.8 to 2.2 cubic foot, your F3 is about 26Hz. Using a plate amp with a low frequency boost, you would go even lower.  Specs:

    T/S parameters measured on drive units that are broken in.

    Effective piston area, Sd

    312 cm*

    Mechanical loss, Rms

    3 kg/s

    Free air resonance, Fs

    10.8 Hz

    Mechanical Q-factor, Qms

    10.3

    Compliance, Cms

    0.48 mm/N

    Equivalent volume, Vas

    66 liters

    Moving mass inclair, Mms

    455 g

    Net weight

    1.75 kg
