7 in. Revelator Woofer Sliced Cone 4 Ohm
7 in. Revelator Woofer Sliced Cone 4 Ohm
close
Code:
18W-4531G-00
Price:
$239.00
Shipping Weight:
8.00
pounds
Quantity in Basket:
None
18W/4531G00
Characteristic sensitivity (2.83V / 1m)
:
90 dB
Recommended frequency range
:
33 - 5000 Hz
Free air resonance frequency, fs
:
33 Hz
DC resistance, Re
:
3.4 ohm
Voice coil inductance, Le
:
0.3 mH
Effective piston area, Sd
:
150 cm²
Moving mass incl. air, md
:
17.5 g
Mechanical loss, Rm
:
0.7 Ns/m
Force factor, BL
:
5.7 Tm
Equivalent volume, Vas
:
42 ltr.
Mechanical Q-factor, Qms
:
5.2
Electrical Q-factor, Qes
:
0.38
Total Q-factor, Qts
:
0.35
Excursion, lin./max.
:
±6.5 / ±11 mm
Voice coil diameter
:
38 mm
Rated power handling
:
70 W
Net weight
:
1.75 kg
