1.5 in. Dome Mid/Tweet
1.5 in. Dome Mid/Tweet
close
Code:
D3806-8200-00
Price:
$192.00
Shipping Weight:
4.00
pounds
Quantity in Basket:
None
D3806/820000
Characteristic sensitivity (2.83V / 1m)
:
90 dB
Recommended frequency range
:
1 - 13.5 kHz
Free air resonance frequency, fs
:
450 Hz
DC resistance, Re
:
5.7 ohm
Voice coil inductance, Le
:
0.04 mH
Effective piston area, Sd
:
14 cm²
Moving mass incl. air, md
:
0.90 g
Force factor, BL
:
3.8 Tm
Excursion, lin./max.
:
±0.4 / ±1.0 mm
Voice coil diameter
:
38 mm
Rated power handling
:
100 W (12 dB/oct.
cross-over at 1 kHz)
Net weight
:
1.2 kg
