29mm Revelator Ring Radiator Neo Magnet, Silver Face
29mm Revelator Ring Radiator Neo Magnet, Silver Face
close
Code:
R2904-7000-00
Price:
$372.00
Shipping Weight:
4.00
pounds
Quantity in Basket:
None
R2904/700000
Characteristic sensitivity (2.83V / 1m)
:
94.5 dB
Recommended frequency range
:
2 - 40 kHz
Free air resonance frequency, fs
:
520 Hz
DC resistance, Re
:
3.0 ohm
Voice coil inductance, Le
:
0.01 mH
Effective piston area, Sd
:
5.6 cm²
Moving mass incl. air, md
:
0.30 g
Force factor, BL
:
2.8 Tm
Excursion, lin./max.
:
±0.20 / ±1.6 mm
Voice coil diameter
:
25 mm
Rated power handling
:
160 W (12 dB/oct.
cross-over at 2.5 kHz)
Net weight
:
0.42 kg
